704/13 VersaChrome HC Bandpassfilter
Produktinformationen "704/13 VersaChrome HC Bandpassfilter"
Durchstimmbar von 0-60°
durchschn. Transmission (0°) > 90%
Zentralwellenlänge (0°) 703,8 nm
Garantierte Minimale Bandbreite (0°) 13 nm
FWHM Bandbreite (0°) (nominal) 20 nm
durchschn. Blockung (0°) OD > 6 275 - 1100 nm
Kantensteilheit 2% (Blockung zu Transmission)
Kantensteilheit 3% (Transmission zu Blockung)
Transmission Band (60°) Tavg > 85%
Zentralwellenlänge (60° ) 627,7 nm
Garantierte Minimale Bandbreite (60°) 13 nm
FWHM Bandbreite (nominal) (60°) 20 nm
durchschn. Blockung (60°) OD > 6 275 - 925 nm
Kantensteilheit (60°) 3% (from blocking to transmission)
Kantensteilheit (60°) 2,5% (from transmission to blocking)
Nominaler effektiver Brechungsindex 1,82
durchschn. Transmission (0°) > 90%
Zentralwellenlänge (0°) 703,8 nm
Garantierte Minimale Bandbreite (0°) 13 nm
FWHM Bandbreite (0°) (nominal) 20 nm
durchschn. Blockung (0°) OD > 6 275 - 1100 nm
Kantensteilheit 2% (Blockung zu Transmission)
Kantensteilheit 3% (Transmission zu Blockung)
Transmission Band (60°) Tavg > 85%
Zentralwellenlänge (60° ) 627,7 nm
Garantierte Minimale Bandbreite (60°) 13 nm
FWHM Bandbreite (nominal) (60°) 20 nm
durchschn. Blockung (60°) OD > 6 275 - 925 nm
Kantensteilheit (60°) 3% (from blocking to transmission)
Kantensteilheit (60°) 2,5% (from transmission to blocking)
Nominaler effektiver Brechungsindex 1,82
Spezifikationen
| OEM-/Originalnummer: | TBP01-704/13-25x36 |
|---|---|
| Transmission Band 1: | Tavg > 90% |
| Center Wavelength 1: | 703.8 nm (minimum) |
| Blocking Band 1: | ODavg > 6 275 - 1100 nm |
| FWHM Bandwidth 1 (nominal): | 20 nm |
| Cutoff Transition Width: | 3% (from transmission to blocking) |
| Guaranteed Minimum Bandwidth 1: | 13 nm |
| Cuton Transition Width: | 2% (from blocking to transmission) |
| Blocking Band 1 (60 deg): | ODavg > 6 275 - 925 nm |
| Transmission Band 1 (60 deg): | Tavg > 85% |
| Center Wavelength 1 (60 deg): | 627.7 nm (maximum) |
| Cutoff Transition Width (60 deg: | 2.5% (from transmission to blocking) |
| Cuton Transition Width (60 deg): | 3% (from blocking to transmission) |
| Angle of Incidence: | 0 - 60 degrees |
| Cone Half-angle: | 0 degrees |
| Optical Damage Rating: | Not tested |
| Substrate type: | low-autofluorescence optical quality glass |
| Transverse Dimensions (L x W): | 25.2 mm x 35.6 mm |
| Transverse Tolerance: | ± 0.1 mm |
| Filter Thickness (unmounted): | 2.0 mm |
| Filter Thickness Tolerance (unm: | ± 0.1 mm |
| Clear Aperture: | ≥ 80% (elliptical) |
| Scratch-Dig: | 60-40 |
| Substrate thickness: | 2.0 mm |
| Orientation: | Reflective surface marked with part number - Orient in direction of incoming light |
| Other physical specs: | Standard Specifications of Our Filters and Beam Splitters |
| : | ---------------------------------------------- |
| Abmessungen: | 25,2 x 35,6 mm |
| Anzahl Bänder/Kanten/Notch: | 1 |
| Art des Filters: | BP Tunable |
| Blockungsstärke: | OD 6 |
| CWL/EdgeWL/NotchWL (nm): | 704 |
| Anwendung (Filter): | Standard/Fluoreszenz |
| Bandbreite (nm): | 13 |
| Substratdicke: | 2,0 mm |
| Scratch-Dig: | 60-40 |
| freie Apertur: | = 80% (elliptical) |
